SUPERNOVA XS RECESSED 330 B
Black - 274 86 3224 B
CRI
CCT
General
| Location | Indoor |
| CCT | 3000K |
| Fixation | Ceiling |
| Installation | Recessed |
| Cutout shape | round |
| Cutout size (mm) | Ø KIT |
| Min. recessed depth (mm) | 200 |
| IP | IP40 |
| Weight (kg) | 3.3 |
| Adjustability | Adjustable 0° / 8° |
| Information | INCL.PC SBL
INCL.LED POWER SUPPLY 1050mA-DC |
Electrical
| Voltage | 110-240V / 50-60Hz |
| Class | II |
| Dimming type | non-dimmable |
| Energy class | E |
Lightsource
| Light source | LED |
| LED information | LED cluster 22W / CRI>80 / 3000K / 2600lm |
| SDCM | SDCM3 |
| Riskgroup | RG0 |
| LM80 | L70 > 60000 |
| LED technics (light source) | 2600lm // 22W // 118lm/W |
| LED technics (luminaire) | 1854lm // 25,3W // 73lm/W |
Additional
| Requirements | SUPERNOVA XS RECESSED KIT 330 |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Ceiling compatibility
Please find an overview of the suitable ceiling types for this specific product.
Ceiling Type
Mounting kit
-
-
-
-
-
-
