LED POWER SUPPLY MULTI-POWER HV

300 90 135

General

Location	Indoor
Cutout shape	round
Cutout size (mm)	90
IP	IP20
Weight (kg)	0.1
Information	OUTPUT: 350mA / 30W / 43-85V-DC 450mA / 35W / 33-85V-DC 500mA / 40W / 30-85V-DC 650mA / 55W / 25-85V-DC 700mA / 60W / 25-86V-DC 900mA / 70W / 25-77V-DC 1050mA / 70W / 25-67V-DC λ > 0,9 Inrush current : 5A - 50µs @ 230V-AC Max. 50 units on circuit breaker B 16A @ 230V-AC

Electrical

Voltage	220-240V / 0\|50-60Hz
Class	II
Dimming type	non-dimmable

Technical data was measured in optimum conditions.

Downloads

Following downloads are available:

Installation manual

Where used

CARREE ST LED IP

CARREE ST LED 92733 A

Product name	Reference number
CARREE ST LED IP 92733	11045 9220
CARREE ST LED IP 93033	11045 9320

White

Finish colours

CARREE ST OK

CARREE ST OK LED 92733 B

Product name	Reference number
CARREE ST OK LED 92733	11046 9220
CARREE ST OK LED 93033	11046 9320

Black

White

Finish colours

CARREE X

CARREE X LED 92733-65 S2 A

Product name	Reference number
CARREE X LED 92733 S1	202 20 811 922
CARREE X LED 93033 S1	202 20 811 932
CARREE X LED 92733-65 S1	202 206 811 922
CARREE X LED 93033-65 S1	202 206 811 932
CARREE X LED 92733-65 S2	202 207 811 922

Alu Grey

Anthracite

White

Finish colours

DEEP RINGO LED

DEEP RINGO X 92733 B

Product name	Reference number
DEEP RINGO LED 92733	202 272 811 922

Black

Brushed Alu

Brushed Anthracite

Brushed Brown Bronze

Brushed Copper

Brushed Gold

Brushed Old Bronze

Finish colours

DEEP RINGO OK LED

DEEP RINGO OK LED 92733 B

Product name	Reference number
DEEP RINGO OK LED 92733	19435 9220
DEEP RINGO OK LED 93033	19435 9320

Black

Brushed Alu

Brushed Anthracite

Brushed Brown Bronze

Brushed Copper

Brushed Gold

Brushed Old Bronze

Cream

Flemish Bronze

Flemish Gold

Gold Coloured

White

Finish colours
