New
CUPPA C SOFT 93040 B-GC
Black-Gold Colored - 28816 9030 B-GC
CUPPA SHADE 120 B
Black - 28800 0010 B
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 3000K-1800K |
| Fixation | Ceiling |
| Installation | Suspended |
| IP | IP20 |
| Weight (kg) | 0.3 |
| Adjustability | non adjustable |
| Information | REFLECTOR WFL-40°
EXCL.DIMMABLE LED POWER SUPPLY 500mA-DC
INCL.1 x CABLE 2 x 0.75mm² / 1,6m |
Electrical
| Class | III |
| Dimming type | depending on type of external power supply |
| Energy class | F |
Lightsource
| Light source | LED |
| LED information | LED array 10,2W / CRI>90 (R9: 50) / 3000K-1800K / 1038lm |
| SDCM | SDCM2 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 1038lm // 10,2W // 109lm/W |
| LED technics (luminaire) | 795lm // 12W // 68lm/W |
Additional
| Remarks | Black cable for B-GC version and grey cable for W-GC version |
| Requirements | CUPPA SHADE
LASS-OH! POWERBOX
LED POWER SUPPLY 350 / 500mA-DC DIM |
| Options | CONNECTION TRIMLESS
CEILING BASE R
CEILING BASE MULTI 1
CEILING BASE MULTI 3 |
Technical data was measured in optimum conditions.
