M20/M26H - HEDRA L 93033 MDL
Available colors
-
GOLD COLORED
473 252 811 932 MDL GC -
BLACK BRONZE
473 252 811 932 MDL BBR
Characteristics
| Location | INTERIOR |
|---|---|
| Recessed depth | n.a. |
| Thickness of mounting surface | n.a. |
| Information |
ADJUSTABLE 0-90°/355° 1 x LED 10,4W / CRI>90 / 3000K / 1128lm REFLECTOR FL-33° EXCL.LED POWER SUPPLY 48V-DC DIMMING BY DALI / 1-10V CONTROL / PUSH BUTTON via 48V modulator Other CRI or KELVIN on request |
| CRI | CRI 90 |
| Colour temp | Warm White (+3000K) |
| LED Technics (light source) | 1128 lm // 10 W // 109 lm/W |
| LED Technics (luminaire) | 566 lm // 12 W // 47 lm/W |
| Electrical | 48V-DC |
| Class | Class III |
| Nett weight | 0.5 Kg |
| IP | IP20 |
| Minimum distance | n.a. |
| Remarks | Take a look at our MAGNETIC PROFILES movie |
| Energy Class | E |
| Options |
DIMMABLE MODULATOR |
| Accessories |
VIZIR HONEYCOMB VIZIR SOFTENING LENS |
| Requirements |
VIZIR TUBE LED POWER SUPPLY 48V-DC |
Description icons:
-
The CE marking on many products shows that the products is compliant with the European regulations.
-
A Class III appliance is designed to be supplied from a separated/safety extra-low voltage (SELV) power source. The voltage from a SELV supply is low enough that under normal conditions a person can safely come into contact with it.
Finish your specification
Options
300 90 011
SMART 48 MODULATOR DIM9
21032 0030
SMART 48 MODULATOR PLUG-IN WD
300 90 012
SMART 48 MODULATOR WD
Accessories
473 03 01
VIZIR HONEYCOMB
473 03 04
VIZIR SOFTENING LENS
Requirements
21012 0230
LED POWER SUPPLY 48V-DC / 100W
300 89 48 100
LED POWER SUPPLY 48V-DC / 100W DIN
21012 0240
LED POWER SUPPLY 48V-DC / 200W
300 89 48 240
LED POWER SUPPLY 48V-DC / 240W DIN
473 01 00
VIZIR TUBE
