MIDISPY ON 83020 ADL W
White - 414 262 832 ADL W
Beam angle
CRI
CCT
General
| Location | Indoor |
| IP | IP20 |
| Weight (kg) | 0.6 |
| Adjustability | 0° to 90° swiveling, 355° rotatable |
| Information | INCL.1 x LENS FL-20°
INCL.1 x 2F 48V ADAPTER
EXCL.LED POWER SUPPLY 48V-DC |
Electrical
| Class | III |
| Dimming type | non-dimmable |
Lightsource
| Light source | LED |
| LED information | LED array 6W / CRI>80 / 3000K / 558lm |
| SDCM | SDCM2 |
| LED technics (light source) | 558lm // 6W // 94lm/W |
| LED technics (luminaire) | 478lm // 6,9W // 69lm/W |
Additional
| Requirements | MIDISPY TUBE
TRACK 2F |
| Options | LED POWER SUPPLY 48V-DC |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | max. devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | LED POWER SUPPLY 48V-DC / 100W DIN | 110-240V | II | non-dimmable | IP20 | round | - | 14 | Add to pinlist |
 | LED POWER SUPPLY 48V-DC / 240W DIN | 100-240V | II | non-dimmable | IP20 | round | - | 35 | Add to pinlist |
