Apto MB (CO)
Discover more
POLESANO 830 SPOT
Available colors
-
ALU GREY-BLACK
43 11 831 A-B -
DARK GREY-BLACK
43 11 831 N-B
Characteristics
| Location | EXTERIOR |
|---|---|
| Fixation | Floor Surface mounted |
| Recessed depth | n.a. |
| Thickness of mounting surface | n.a. |
| Information |
360° ADJUSTABLE 16 x LENS SP-15° LED CLUSTER 42W / CRI>80 / 3000K / 4481lm INCL.DIMMABLE LED POWER SUPPLY 900mA-DC DIMMING BY DALI-2 λ > 0,9 Inrush current : 32A - 355µs @ 230V-AC Max. 10 units on circuit breaker B 16A @ 230V-AC (13 units on B 20A) Powdercoated with 'Qualicoat ' quality label |
| CRI | CRI 80 |
| Colour temp | Warm White (+3000K) |
| LED Technics (light source) | 4481 lm // 42 W // 107 lm/W |
| LED Technics (luminaire) | 3563 lm // 48 W // 74 lm/W |
| Electrical | 220-240V / 0|50-60Hz |
| Class | Class I |
| Nett weight | 5 Kg |
| IP | IP66 |
| Minimum distance | n.a. |
| Remarks | Take a look at the POLESANO brochure |
| Energy Class | E |
| Accessories |
HONEYCOMB S105 LINEAR SPREAD LENS S105 |
| Requirements |
POLESANO POLE |
Description icons:
-
The CE marking on many products shows that the products is compliant with the European regulations.
-
A Class I electrical appliance must have its chassis connected to electrical earth (ground) by an earth conductor.
-
Floor surface mounted
Finish your specification
Accessories
431 03 01
HONEYCOMB S105
431 03 02
LINEAR SPREAD LENS S105
Requirements
431 400 111 11
POLESANO 4M - 1 ANCHORED
431 400 221 11
POLESANO 4M - 1 BASE
431 400 111 211
POLESANO 4M - 21L ANCHORED
431 400 221 211
POLESANO 4M - 21L BASE
431 400 111 221
POLESANO 4M - 22L ANCHORED
431 400 221 221
POLESANO 4M - 22L BASE
431 400 111 31
POLESANO 4M - 3 ANCHORED
431 400 221 31
POLESANO 4M - 3 BASE
431 400 111 41
POLESANO 4M - 4 ANCHORED
431 400 221 41
POLESANO 4M - 4 BASE
431 600 121 11
POLESANO 6M - 1 ANCHORED
431 600 321 11
POLESANO 6M - 1 BASE
431 600 121 211
POLESANO 6M - 21L ANCHORED
431 600 321 211
POLESANO 6M - 21L BASE
431 600 121 221
POLESANO 6M - 22L ANCHORED
431 600 321 221
POLESANO 6M - 22L BASE
431 600 121 31
POLESANO 6M - 3 ANCHORED
431 600 321 31
POLESANO 6M - 3 BASE
431 600 121 41
POLESANO 6M - 4 ANCHORED
431 600 321 41
POLESANO 6M - 4 BASE
Discover more about the POLESANO family
Polesano is the result of the first collaboration between Delta Light and Dean Skira. The goal was to develop a new lighting concept designed specifically for urban settings, whether it is a pedestrian pathway, roadway, park, square, façade or landscape. The concept needed to provide maximum flexibility for the designer while maintaining the same aesthetic for the entire system, regardless of the area. Polesano is a striking combination of modularity and flexibility that allows the designer to meet the specific functional and aesthetic requirements of any project. Integrating video surveillance, Wi-Fi, speakers or other Internet of Things elements is a next step in the development of Polesano. 'The main idea behind “POLESANO” was to create a “device” that combines all types of lighting into a single aesthetically unique structure, where the pole and the fitting become one body,' explains Dean Skira. Polesano is characterized by a pure, minimalist design that doesn’t overpower its environment. A focus on modularity and flexibility allows Polesano to meet its multi-zone lighting requirements in a continuous and uniform design language. Thanks to different optics and sizes, Polesano enables both precise lighting and a combination of lighter and darker zones for an effective blend of landscape, social interaction and lighting. POLESANO brochure
