POLESANO 840 STREET A-B
Alu Grey-Black - 43 11 844 A-B
CRI
Beam angle
CCT
General
| Location | Outdoor |
| CCT | 4000K |
| Fixation | Pole |
| Installation | Pole top |
| IP | IP66 |
| IK | IK08 |
| Weight (kg) | 5 |
| Adjustability | 360° swiveling, 360° rotatable |
| Information | 4 x LENS STREET
INCL.DIMMABLE LED POWER SUPPLY 900mA-DC
λ > 0,9
Inrush current : 32A - 355µs @ 230V-AC
Max. 10 units on circuit breaker B 16A @ 230V-AC (13 units on B 20A) |
Electrical
| Voltage | 220-240V / 0|50-60Hz |
| Class | I |
| Dimming type | DALI |
| Energy class | E |
| Certificates | CB, EAC, ENEC, ENEC+, RCM |
Lightsource
| Light source | LED |
| LED information | LED cluster 41,6W / CRI>80 (R9: 26) / 4000K / 5040lm |
| TM-30 Values | Rf: 87 / Rg: 97 |
| SDCM | SDCM3 |
| Riskgroup | RG1 |
| LM80 | L80 > 120000 |
| LED technics (light source) | 5040lm // 41,6W // 121lm/W |
| LED technics (luminaire) | 2622lm // 47,8W // 55lm/W |
Additional
| Remarks | |
| Requirements | POLESANO POLE |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
Pole
