Apto MB (CO)
Discover more
SPY 66 ON 93030
Available colors
-
BLACK
24623 9320 B -
WHITE
24623 9320 W
Characteristics
| Location | INTERIOR |
|---|---|
| Fixation | Ceiling Surface mounted |
| Recessed depth | n.a. |
| Thickness of mounting surface | n.a. |
| Information |
ADJUSTABLE 0-90°/355° 1 x LED 11,6-25W / CRI>90 / 3000K / 1524-2811lm REFLECTOR FL-30° EXCL.LED POWER SUPPLY 350-700mA-DC Optional REFLECTORS 18° & 45° available Other CRI or KELVIN on request |
| CRI | CRI 90 |
| Colour temp | Warm White (+3000K) |
| LED Technics (light source) | 2811 lm // 25 W // 112 lm/W |
| LED Technics (luminaire) | 1937 lm // 28 W // 67 lm/W |
| Electrical | |
| Class | Class III |
| Nett weight | 0.7 Kg |
| IP | IP20 |
| Minimum distance | n.a. |
| Remarks | GLASS / LENS 57: max. 500mA |
| Energy Class | E |
| Options |
COVERSET R 90-100 |
| Accessories |
HONEYCOMB 57 SPREAD LENS 57 LINEAR SPREAD LENS 57 SOFTENING LENS 57 GLASS SBL 57 |
| Requirements |
SPY 66 TUBE LED POWER SUPPLY 350 / 500 / 700mA-DC DIM |
Description icons:
-
The CE marking on many products shows that the products is compliant with the European regulations.
-
A Class III appliance is designed to be supplied from a separated/safety extra-low voltage (SELV) power source. The voltage from a SELV supply is low enough that under normal conditions a person can safely come into contact with it.
-
Ceiling surface mounted
Finish your specification
Options
204 00 100
COVERSET R 100
204 00 90
COVERSET R 90
24611 0220
SPY 66 REFLECTOR 18°
24611 0230
SPY 66 REFLECTOR 30°
24611 0240
SPY 66 REFLECTOR 45°
Accessories
24611 0160
GLASS SBL 57
24611 0210
HONEYCOMB 57 DOUBLE USE
24611 0150
HONEYCOMB 57 SINGLE USE
24611 0170
LINEAR SPREAD LENS 57
24611 0190
SOFTENING LENS 57
24611 0200
SPREAD LENS 57
Requirements
300 48 350 ED1
LED POWER CONVERTER 48V-DC to 350 mA-DC / 15W DIM1
300 48 350 ED5
LED POWER CONVERTER 48V-DC to 350 mA-DC / 15W DIM5
300 48 350 MDL
LED POWER CONVERTER 48V-DC to 350 mA-DC / 15W MDL
300 48 350 WDL
LED POWER CONVERTER 48V-DC to 350 mA-DC / 15W WDL
300 48 500 ED1
LED POWER CONVERTER 48V-DC to 500 mA-DC / 22W DIM1
300 48 500 ED5
LED POWER CONVERTER 48V-DC to 500 mA-DC / 22W DIM5
300 48 500 MDL
LED POWER CONVERTER 48V-DC to 500 mA-DC / 22W MDL
300 48 500 WDL
LED POWER CONVERTER 48V-DC to 500 mA-DC / 22W WDL
300 48 700 ED1
LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W DIM1
300 48 700 ED5
LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W DIM5
300 48 700 MDL
LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W MDL
300 48 700 WDL
LED POWER CONVERTER 48V-DC to 700 mA-DC / 25W WDL
21012 0010
LED POWER SUPPLY MULTI POWER
21012 0021
LED POWER SUPPLY MULTI POWER DIM1
21012 0035
LED POWER SUPPLY MULTI POWER DIM5
21012 005W
LED POWER SUPPLY MULTI-POWER COMPACT WDL
300 90 68
LED POWER SUPPLY MULTI-POWER DIM5
300 90 61
LED POWER SUPPLY MULTI-POWER DIM6
300 90 124
LED POWER SUPPLY MULTI-POWER DIM7
300 90 64
LED POWER SUPPLY MULTI-POWER DIM7
300 90 63
LED POWER SUPPLY MULTI-POWER DIM9
300 90 135
LED POWER SUPPLY MULTI-POWER HV
300 90 69
LED POWER SUPPLY MULTI-POWER HV DIM9
300 90 125
LED POWER SUPPLY MULTI-POWER MINI DIM5
21012 004W
LED POWER SUPPLY MULTI-POWER WDL
24611 0100
SPY 66 TUBE
Discover more about the SPY family
Minimalism, functionality and versatility are the key terms to describe this extensive collection. The Spy was designed to meet multiple lighting requirements, an ideal solution for accent lighting in residential, hospitality or commercial spaces. The range features low to high lumen packages, narrow to wide beam options, standard or specific LED colours, recessed to surface mounted and track applications, different colour finishes and combinations, and can be equipped with multiple light refining accessories. Following the constant changes in the world of LEDs and optics and the evolution to better user comfort with more precise optics and better light control, the complete Spy range has been upgraded. The result? Fresh shapes and additional finishing colours, better light comfort through hybrid optics, improved LED colour consistency and new perspectives with Tunable White and Soft Dim. The renewed Spy family comes in diameters of 27, 39, 52, 66 and 90 millimeters, a range of spotlights to fit any purpose. While the smaller versions come in the lively colours Flemish Bronze, Flemish Gold and Gold Coloured, the bigger Spy’s offer Tunable White and Soft Dim solutions in multiple beam angles. PATENTED EX-CENTRIC ROTATION SYSTEM Spy brochure
