TWEETER X W 930 N
Anthracite - 206 40 811 930 N
CRI
CCT
General
| Location | Outdoor |
| Fixation | Wall |
| Installation | Surface mounted |
| IP | IP54 |
| IK | IK03 |
| Weight (kg) | 1 |
| Adjustability | 0° to 45° swiveling, 350° rotatable |
| Information | INCL.PC SBL
INCL.LED POWER SUPPLY 350mA-DC
Patented Ex-centric Rotation System |
Electrical
| Class | II |
| Dimming type | non-dimmable |
| Energy class | E |
Lightsource
| Light source | LED |
| LED information | LED array 7,1W / CRI>90 (R9: 52) / 3000K / 812lm |
| TM-30 Values | Rf: 90 / Rg: 99 |
| SDCM | SDCM2 |
| Riskgroup | RG1 |
| LM80 | L90B10 > 50000 |
| LED technics (light source) | 812lm // 7,1W // 115lm/W |
| LED technics (luminaire) | 460lm // 8W // 56lm/W |
Technical data was measured in optimum conditions.
