INFORM SQ P144-5 DOWN 84067 B-MMAT
Black-Gold Matt - 25513 8420 B-MMAT
CRI
Beam angle
CCT
General
| Location | Indoor |
| CCT | 4000K |
| Fixation | Ceiling |
| Installation | Suspended |
| IP | IP20 |
| Weight (kg) | 1 |
| Adjustability | non adjustable |
| Information | 60 x REFLECTOR FL-67°
EXCL.LED POWER SUPPLY 500/750mA-DC
INCL.2 x CABLE SUSPENSION SINGLE AUTO. 1,6m
POWER VIA CABLE SUSPENSION
MELANOPIC LIGHT TECHNOLOGY |
Electrical
| Class | III |
| Dimming type | depending on type of external power supply |
| Energy class | B |
Lightsource
| Light source | LED |
| LED information | LED cluster 16,4-25,3W / CRI>80 (R9: 50) / 4000K / 2946-4326lm |
| TM-30 Values | Rf: 85 / Rg: 94 |
| SDCM | SDCM3 |
| Riskgroup | RG2 |
| LM80 | L90 > 60000 |
| LED technics (light source) | 4326lm // 25,3W // 171lm/W |
| LED technics (luminaire) | 3777lm // 29W // 130lm/W |
Additional
| Requirements | INFORM SQ POWERBOX 50W (DIM5)
INFORM POWER SUPPLY 45W + SUSPENSION+CONNECTION ST |
Technical data was measured in optimum conditions.
Downloads
Following downloads are available:
Finish your specifications
Use the information listed below to complete your product
requirement
LED power supplies
| Product name | Voltage | Class | Dimming type | IP | Cutout shape | Cutout size | devices / supply | ||
|---|---|---|---|---|---|---|---|---|---|
 | INFORM POWER SUPPLY 45W DIM5 | 220-240V | I | DALI | IP20 | - | - | 1 | Add to pinlist |
 | INFORM POWER SUPPLY 45W | 220-240V | I | non-dimmable | IP20 | - | - | 1 | Add to pinlist |
Electric connection parts
| Product name | Class | ||
|---|---|---|---|
 | SUSPENSION + CONNECTION ST B | III | Add to pinlist |
 | SUSPENSION + CONNECTION ST W | III | Add to pinlist |
